Professional Panel Pool Kits
Kafko Professional Pool Kits have been designed for the experienced pool builder in mind. Consisting of ‘X-treme Polymer Panels and Polymer or Steel Bracing these pools typically have a shallow and deep end pool depth configuration.
Kafko Professional ‘X- treme’ Polymer pool panel sets are available in 4ft (1.22m) or 5ft (1.5m) depths with polymer bracing at 4ft increments. All panels prior to delivery, are pre-cut at our warehouse using a custom made jig to enable Skimmer(s), Light fitting(s) etc to be installed accurately and with ease. Colours may vary.
Panel kits have two depth options – 4ft & 5ft
4′ Pool Depth Option
Excavation:- Dig dimensions to standard pool depth.
| Pool Size | A | B | C |
|---|---|---|---|
| 12' x 20' | 12 | 20' | 4'21/2' |
| 12' x 24' | 12' | 24' | 4'21/2' |
| 12" x 28" | 12' | 28' | 4'21/2' |
| 14' x 30' | 14' | 30' | 4'21/2' |
5′ Pool Depth Option
An optional 5′ pool depth is also available at no extra cost. The same liner that is used for a 4′ depth pool can also be used for a 5′ depth pool. The liner material is expandable and will stretch into position as long as the excavation is carried out to the dimensions carried out below.
Note: Please make sure your dealer is aware of your intentions to increase the depth of the pool as this may alter the plumbing configuration and heater sizing that is required for your pool
| Pool Size | C | D | E | F | G |
|---|---|---|---|---|---|
| 12' x 20' | 4'21/2' | 14' | 3'6" | 5' | 5'41/2" |
| 12' x 24' | 4'21/2' | 18' | 3'6" | 5' | 5'41/2" |
| 12" x 28" | 4'21/2' | 22' | 3'6" | 5' | 5'41/2" |
| 14' x 30' | 4'21/2' | 24' | 3'6" | 7' | 5'41/2" |
Items included
- Polymer Panel (s)
- Polymer Bracing
- Corner Post
- Hardware
- Steel Pins
- 6″ Radius Corner Inserts
Option
- 2ft Radius Corner (Excluding 5ft Panel)
| Pool Size | 24 x 12 | 28 x 14 | 30 x 14 | 30 x 15 | 32 x 16 | 33 x 16 | 36 x 18 | 40 x 20 |
|---|---|---|---|---|---|---|---|---|
| Panel Set | 4′ | 4′ | 4′ | 4′ | 4′ | 4′ | 4′ | 4′ |
| Price | £7,141.00 | £8,661.00 | £9340.00 | £9,599.00 | £9,582.00 | £10,203.00 | £11,101.00 | £12,022.00 |
| Panel Set | 5′ | 5′ | 5′ | 5′ | 5′ | 5′ | 5′ | 5′ |
| Price | £8,778.00 | £10,663.00 | £11,517.00 | £11,834.00 | £11,780.00 | £12,560.00 | £13,665.00 | £14,872.00 |
| Inlet(s) Pre-fitted | £65.80 | £65.80 | £65.80 | £65.80 | £65.80 | £65.80 | £65.80 | £65.80 |
| Skimmer(s) Pre-fitted | £267.00 | £267.00 | £267.00 | £267.00 | £267.00 | £267.00 | £267.00 | £267.00 |
| 6″Radius Corner Insert for 4′ Panels (set 4) | £294.00 | |||||||
| 6″Radius Corner Insert for 5′ Panels (set 4) | £610.00 |
All prices exclude VAT and delivery.
X-treme panels have a much stronger internal rib support and can be used in conjunction with XPS extruded polystyrene. This swimming pool insulation panel system is ideal for installations that have to be Part L compliant.
If you’re willing to spend more, then you may be interested in taking a look at our selection of Tilestone pools.
Tips for building a DIY Swimming Pool
- Budget for add-ons. Whilst our panel pool kit provides you with the basic parts to build your pool, you may wish to budget for add-ons such as outdoor lighting, safety covers, solar covers & additional landscaping.
- Consider your location carefully. Once installed, the pool will not be able to be moved unless at a very high cost. Draw a scale plan of your garden and ensure you have the right space before building. Keep away from trees or shaded areas and ensure no electric cables, water or gas pipes run through the proposed site.
- Tools for the job. You will require an extensive amount of tools to complete the task, including specialist equipment such as an industrial vacuum cleaner and angle grinder.
- Manpower. If you are planning on building the pool without any heavy machinery then you’ll likely need the help of a team of people to assist with the initial digging.
- Time. Ensure that you’ve blocked out enough spare time to complete this project, as once you start you’ll want to ensure that each task is completed within quick succession of one another.
- Materials. On top of the initial pool kit expense, you will also require standard building materials including soft sand, ballast, cement and 40mm shingle. Make sure you have all of these materials to hand before starting the build.
- Get help if needed. If you aren’t confident with a certain aspect of the process then seek help for those parts. You may be able to excavate and level the hole to your satisfaction, but might not be able to execute the plumbing. Hire someone to help rather than sacrifice quality.
Do I need planning permission for a swimming pool?
In most cases, you do not need planning permission to build a DIY swimming pool. However, you may need to contact your planning office if you are living in:
- an area of outstanding natural beauty
- conservation area
- green belt
- a listed building
How long does it take to get council approval for a pool?
Approval from a council for your pool build, should you need it, could be expected to be delivered between 8 and 16 weeks, depending on the circumstances. Planning authorities are duty-bound to make decisions on applications quickly, and as such, there is a statutory determination period of 8 weeks for ‘straightforward planning applications’. In cases where an Environmental Impact Assessment is needed, this period is extended to 16 weeks.
How do you heat a swimming pool?
Swimming pools can be heated using a range of products, including heat pumps &, solar panels. Each has its own set of advantages and drawbacks, depending on your budget and the size of the pool.
